Is the Angled Adjustable Triple Plug Connector with Male Thread, Type R52 compatible with both vacuum and compressed air systems up to 16 bar?

Yes. The Angled Adjustable Triple Plug Connector with Male Thread, Type R52 is compatible with both vacuum and compressed air systems up to 16 bar. Made from nickel-plated brass with NBR seals, it supports operation from -20°C to +80°C, offers secure pneumatic and mechanical sealing, and is designed for repeated assembly/disassembly without loss of tightness.

Can the Angled Adjustable Triple Plug Connector with Male Thread, Type R52 be used with different tubing materials without affecting seal integrity?

Yes — the Angled Adjustable Triple Plug Connector with Male Thread, Type R52 can be used with different tubing materials without compromising seal integrity, provided the tubing is compatible with the connector’s NBR seals and the application conditions. Key points: - NBR seals: Nitrile (NBR) provides excellent sealing for air and vacuum and tolerates oils and many common pneumatic fluids; it performs well between –20°C and +80°C. - Material compatibility: Tubing made of compatible polymers (e.g., polyurethane, nylon, and many polyethylenes) or metal (brass, stainless steel) that do not chemically attack NBR will maintain a reliable seal. - Pressure and temperature limits: Ensure tubing and fittings meet the connector’s working pressure (up to 16 bar) and operating temperature range; incompatible materials that deform, harden, or swell under these conditions can impair sealing. - Mechanical fit and surface finish: Proper tube diameter, roundness and a smooth cut are required for optimal engagement with the push-fit/collet mechanism; damaged or undersized tubing can leak. - Media and environment: If exposed to aggressive chemicals, high temperatures, or special gases, verify chemical compatibility with NBR; for incompatible media, choose a connector with a different seal material. In summary: Yes, with tubing materials that are chemically and mechanically compatible with NBR, and that meet the connector’s pressure/temperature requirements, the Angled Adjustable Triple Plug Connector with Male Thread, Type R52 will maintain seal integrity.

Angled Adjustable Triple Plug Connector with Male Thread, Type R52

All products, Push-in fittings/

Additional information

Material	B – brass (bronze)

The angled plug connector, adjustable triple with external thread type R52, is a reliable solution designed for efficient and secure connections of wires and components in pneumatic systems. Manufactured from high-quality nickel-plated brass, it ensures durability, resistance to wear, and long-lasting performance even in demanding environments. Its innovative design allows for quick and easy assembly and disassembly, enabling multiple uses without compromising sealing integrity on either the mechanical or pneumatic side. With a working pressure of up to 16 bar and compatibility with both vacuum and air, this connector guarantees versatility across a wide range of applications. Operating effectively in temperatures from -20°C to +80°C and equipped with NBR sealing, it provides excellent tightness and stability, ensuring consistent performance. This makes the R52 connector an ideal choice for industries seeking reliable, efficient, and maintenance-friendly pneumatic connections.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
MW-2L52002	Triple adjustable angle connector RL52 hose 4 mm, GZ BSP 1/8"	-	16	In stock	Enquiry
MW-2L52008	Triple adjustable angle connector RL52 hose 6 mm, GZ BSP 1/8"	-	16	In stock	Enquiry
MW-2L52009	Triple adjustable angle connector RL52 hose 6 mm, GZ BSP 1/4"	-	16	In stock	Enquiry
MW-2L52010	Triple adjustable angle connector RL52 hose 8 mm, GZ BSP 1/8"	-	16	In stock	Enquiry
MW-2L52011	Triple adjustable angle connector RL52 hose 8 mm, GZ BSP 1/4"	-	16	In stock	Enquiry
MW-2L52013	Triple adjustable angle connector RL52 hose 10 mm, GZ BSP 1/4"	-	16	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +91 8 925 918 796 or email us: chennai@tubes-international.com

SEND ENQUIRY

The angled plug connector, adjustable triple with external thread type R52, is a reliable solution designed for efficient and secure connections of wires and components in pneumatic systems. Manufactured from high-quality nickel-plated brass, it ensures durability, resistance to wear, and long-lasting performance even in demanding environments. Its innovative design allows for quick and easy assembly and disassembly, enabling multiple uses without compromising sealing integrity on either the mechanical or pneumatic side. With a working pressure of up to 16 bar and compatibility with both vacuum and air, this connector guarantees versatility across a wide range of applications. Operating effectively in temperatures from -20°C to +80°C and equipped with NBR sealing, it provides excellent tightness and stability, ensuring consistent performance. This makes the R52 connector an ideal choice for industries seeking reliable, efficient, and maintenance-friendly pneumatic connections.
