Is the Twisted 90° Pneumatic Pipe & Hose Coupling, Type B6 compatible with reinforcing sleeves Type B12 for high-pressure hose installations?

Yes. The Twisted 90° Pneumatic Pipe & Hose Coupling, Type B6 is compatible with reinforcing sleeves Type B12 for high-pressure hose installations. The B6 fitting is designed for secure connections between copper pipes and plastic hoses and is rated to a working pressure of up to 60 bar, making it suitable for high-pressure systems. For hose connections, the use of reinforcing sleeves Type B12 is recommended to enhance safety and maintain a tight, leak-free seal. Together, the B6 fitting’s robust nickel-plated brass construction and the B12 reinforcing sleeves provide reliable, durable, and pressure-resistant hose assemblies for industrial and technical installations.

Can the Twisted 90° Pneumatic Pipe & Hose Coupling, Type B6 be used with different hose materials when fitted with reinforcing sleeves Type B12 for high-pressure applications?

Yes. The Twisted 90° Pneumatic Pipe & Hose Coupling, Type B6 can be used with different hose materials in high‑pressure applications provided they are fitted with the recommended reinforcing sleeves, Type B12. The coupling is rated to a working pressure of up to 60 bar and is designed to form secure, leak‑free connections between copper pipes and plastic hoses; the B12 sleeves increase hose stiffness at the connection point, prevent extrusion or blowout, and help maintain a tight seal under high pressure. Ensure the selected hose material is compatible with the media, temperature, and mechanical stresses of your application and that the sleeve is correctly sized and installed for that hose type to achieve the rated performance and safety.

Twisted 90° Pneumatic Pipe & Hose Coupling, Type B6

All products, Cutting ring fittings/

Additional information

Material	B – brass (bronze)

The 90° angle fitting type B6 with locking ring is a reliable solution for secure and durable connections between copper pipes and plastic hoses, ensuring precision and stability in demanding applications. Manufactured from high-quality nickel-plated brass, it offers excellent resistance to corrosion and wear, guaranteeing long-lasting performance even under intensive use. With a working pressure of up to 60 bar, this fitting is engineered to meet the requirements of high-pressure systems, making it ideal for both industrial and technical installations. For hose connections, the use of reinforcing sleeves type B12 is recommended to enhance safety and maintain a tight, leak-free seal. Its robust design, combined with easy assembly, provides professionals with a dependable component that ensures efficiency, reliability, and peace of mind in every connection.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]
MW-2206001	Angle connector (elbow) B6, tube (hose) 4/2 - tube (hose) 4/2	-	60
MW-2206002	Angle connector (elbow) B6, tube (hose) 6/4 - tube (hose) 6/4	-	60
MW-2206003	Angle connector (elbow) B6, tube (hose) 8/6 - tube (hose) 8/6	-	60
MW-2206004	Angle connector (elbow) B6, tube (hose) 10/8 - tube (hose) 10/8	-	60
MW-2206005	Angle connector (elbow) B6, tube (hose) 12/10 - tube (hose) 12/10	-	60
MW-2206006	Angle connector (elbow) B6, tube (hose) 15/12 - tube (hose) 15/12	-	60

The 90° angle fitting type B6 with locking ring is a reliable solution for secure and durable connections between copper pipes and plastic hoses, ensuring precision and stability in demanding applications. Manufactured from high-quality nickel-plated brass, it offers excellent resistance to corrosion and wear, guaranteeing long-lasting performance even under intensive use. With a working pressure of up to 60 bar, this fitting is engineered to meet the requirements of high-pressure systems, making it ideal for both industrial and technical installations. For hose connections, the use of reinforcing sleeves type B12 is recommended to enhance safety and maintain a tight, leak-free seal. Its robust design, combined with easy assembly, provides professionals with a dependable component that ensures efficiency, reliability, and peace of mind in every connection.
