Is the Twisted Tee Connector for Pneumatic Pipes & Hoses "T" with BSPT Male Thread, Type B7 compatible with reinforced plastic hoses using B12 sleeves?

Yes. The Twisted Tee Connector for Pneumatic Pipes & Hoses "T" with BSPT Male Thread, Type B7 is compatible with reinforced plastic hoses when used together with B12 reinforcing sleeves. The product description explicitly recommends reinforcing sleeves (B12) for plastic hoses to ensure maximum stability and leak-free operation. Made of nickel-plated brass with an integrated locking ring and rated up to 60 bar, the fitting is designed to provide secure, durable connections between copper pipes and plastic hoses when the B12 sleeves are fitted.

Can the Twisted Tee Connector for Pneumatic Pipes & Hoses "T" with BSPT Male Thread, Type B7 be used with non-reinforced plastic hoses without B12 sleeves?

Twisted Tee Connector for Pneumatic Pipes & Hoses "T" with BSPT Male Thread, Type B7 can be used with non-reinforced plastic hoses, but it is not recommended. The product description states that when used with plastic hoses, reinforcing sleeves (B12) are recommended to ensure maximum stability and leak-free operation. Without B12 sleeves, non-reinforced hoses may be less stable under pressure (working pressure up to 60 bar) and more prone to deformation, slipping, or leaks. For safe, durable, and reliable connections—especially in demanding or high-pressure applications—use B12 reinforcing sleeves with the fitting.

Twisted Tee Connector for Pneumatic Pipes & Hoses “T” with BSPT Male Thread, Type B7

All products, Cutting ring fittings/

Additional information

Material	B – brass (bronze)

The T-shaped fitting with external BSPT thread type B7 and integrated locking ring is a reliable solution for creating durable and secure connections between copper pipes and plastic hoses. Crafted from high-quality nickel-plated brass, it ensures excellent resistance to corrosion and long-lasting performance even under demanding conditions. With a working pressure of up to 60 bar, this fitting delivers outstanding strength and safety in both industrial and domestic applications. When used with plastic hoses, reinforcing sleeves (B12) are recommended to guarantee maximum stability and leak-free operation. Its precise design allows for quick installation, while the robust construction makes it an ideal choice for systems requiring efficiency, reliability, and professional-grade durability.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]
MW-2207001	T-branch connector B7, 2 x tube (hose) 4/2 / GZ BSPT 1/8"	-	60
MW-2207002	T-branch connector B7, 2 x tube (hose) 6/4 / GZ BSPT 1/8"	-	60
MW-2207003	T-branch connector B7, 2 x tube (hose) 6/4 / GZ BSPT 1/4"	-	60
MW-2207004	T-branch connector B7, 2 x tube (hose) 8/6 / GZ BSPT 1/8	-	60
MW-2207005	T-branch connector B7, 2 x tube (hose) 8/6 / GZ BSPT 1/4"	-	60
MW-2207006	T-branch connector B7, 2 x tube (hose) 8/6 / GZ BSPT 3/8	-	60
MW-2207007	T-branch connector B7, 2 x tube (hose) 10/8 / GZ BSPT 1/4"	-	60
MW-2207008	T-branch connector B7, 2 x tube (hose) 10/8 / GZ BSPT 3/8	-	60
MW-2207010	T-branch connector B7, 2 x tube (hose) 12/10 / GZ BSPT 3/8	-	60
MW-2207011	T-branch connector B7, 2 x tube (hose) 12/10 / GZ BSPT 1/2"	-	60
MW-2207012	T-branch connector B7, 2 x tube (hose) 15/12 / GZ BSPT 1/2	-	60

The T-shaped fitting with external BSPT thread type B7 and integrated locking ring is a reliable solution for creating durable and secure connections between copper pipes and plastic hoses. Crafted from high-quality nickel-plated brass, it ensures excellent resistance to corrosion and long-lasting performance even under demanding conditions. With a working pressure of up to 60 bar, this fitting delivers outstanding strength and safety in both industrial and domestic applications. When used with plastic hoses, reinforcing sleeves (B12) are recommended to guarantee maximum stability and leak-free operation. Its precise design allows for quick installation, while the robust construction makes it an ideal choice for systems requiring efficiency, reliability, and professional-grade durability.
