Can the 45° SAE 3000 Flange End, Light Series, Carbon Steel Fitting, Type NSK311 be crimped onto 4SP/4SH/R13/R15 hoses without removing the rubber cover using the TI-N sleeve?

Yes. The 45° SAE 3000 Flange End, Light Series, Carbon Steel Fitting, Type NSK311 can be crimped onto 4SP/4SH/R13/R15 hoses using the TI-N sleeve without removing the hose rubber cover. The fitting is specifically designed as a NON SKIVE (SFL 45) flange for crimping with those hose types and the TI-N crimping sleeve, enabling secure installation while maintaining the hose cover. Constructed from carbon steel with protective galvanization, it ensures durable, leak-resistant connections and simplifies assembly in demanding hydraulic applications.

Is the 45° SAE 3000 Flange End, Light Series, Carbon Steel Fitting, Type NSK311 compatible with standard crimping machines using the TI-N sleeve?

Yes. The 45° SAE 3000 Flange End, Light Series, Carbon Steel Fitting, Type NSK311 (NON SKIVE SFL 45) is designed specifically for crimping with the TI-N sleeve and is compatible with standard crimping machines used for hoses types 4SP, 4SH, R13, and R15. Its non-skive design allows crimping without removing the hose rubber cover, and the combination of the SFL 45 and TI-N sleeve ensures secure, leak-resistant connections, reliable alignment, and efficient installation on conventional crimping equipment.

45° SAE 3000 Flange End, Light Series, Carbon Steel Fitting, Type NSK311

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)
Standard length [m]	2

The 45° NON SKIVE SAE 3000 flange end (SFL 45) in lightweight series is a high-performance fitting engineered for demanding hydraulic applications, ensuring secure and durable connections. Specifically designed for crimping with hoses of types 4SP, 4SH, R13, and R15, it is used in combination with the reliable TI-N crimping sleeve, delivering maximum efficiency without the need to remove the hose’s rubber cover during installation. Manufactured from robust carbon steel and finished with a protective galvanization layer, the flange offers excellent resistance to wear, corrosion, and harsh working environments. Its precise 45° angle construction guarantees optimal alignment and flexibility in complex hydraulic systems, reducing assembly time and minimizing the risk of leakage. This solution is ideal for industries requiring both strength and reliability, such as construction, mining, and heavy machinery, where uninterrupted performance and safety are crucial. By combining advanced engineering with ease of installation, the SFL 45 flange end provides a cost-effective and long-lasting connection that enhances the overall efficiency of hydraulic systems.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-NSK311-12-12	End fitting 45° NON SKIVE SAE 3000 3/4", hose 3/4"	20	350	In stock	Enquiry
TI-NSK311-12-16	End fitting 45° NON SKIVE SAE 3000 3/4", hose 1"	25	350	In stock	Enquiry
TI-NSK311-16-12	End fitting 45° NON SKIVE SAE 3000 1", hose 3/4"	20	350	In stock	Enquiry
TI-NSK311-16-16	End fitting 45° NON SKIVE SAE 3000 1", hose 1"	25	350	In stock	Enquiry
TI-NSK311-20-16	End fitting 45° NON SKIVE SAE 3000 1.1.4", hose 1"	25	280	In stock	Enquiry
TI-NSK311-20-20	End fitting 45° NON SKIVE SAE 3000 1.1/4", hose 1.1/4"	32	280	In stock	Enquiry
TI-NSK311-24-20	End fitting 45° NON SKIVE SAE 3000 1.1.2", hose 1.1/4"	32	210	In stock	Enquiry
TI-NSK311-24-24	End fitting 45° NON SKIVE SAE 3000 1.1.2", hose 1.1/2"	38	210	In stock	Enquiry
TI-NSK311-32-24	End fitting 45° NON SKIVE SAE 3000 2", hose 1.1/2"	38	210	In stock	Enquiry
TI-NSK311-32-32	End fitting 45° NON SKIVE SAE 3000 2", hose 2"	50	210	In stock	Enquiry
TI-NSK311-40-32	End fitting 45° NON SKIVE SAE 3000 2.1/2", hose 2"	50	175	In stock	Enquiry
