Is the Aluminum Pneumatic Valve VOR with Enhanced Signal Control compatible with my system’s pressure (2–10 bar) and temperature (-10°C to +80°C) ranges?

Yes. The Aluminum Pneumatic Valve VOR with Enhanced Signal Control is explicitly specified to operate within a pressure range of 2–10 bar and a temperature range of −10°C to +80°C. Its aluminum body and NBR sealing are designed to ensure reliable performance and tightness across those conditions, making it compatible with your system’s stated pressure and temperature ranges.

Does the Aluminum Pneumatic Valve VOR with Enhanced Signal Control require specific mounting orientation or clearance for reliable operation?

Aluminum Pneumatic Valve VOR with Enhanced Signal Control does not require a strict mounting orientation for reliable operation. Its compact aluminum body and NBR sealing are designed for flexible integration into various pneumatic systems. However, for optimal performance and maintenance access, mount the valve so that ports are easily reachable and any condensate or debris cannot collect in the signal passages. Ensure a minimum clearance around the valve to allow for tubing connections, visual inspection, and replacement—typically a few centimeters on all sides depending on installation layout. Also avoid mounting locations exposed to excessive vibration, direct heat sources beyond the specified -10°C to +80°C range, or environments that could introduce contaminants; use appropriate filtration and drainage upstream if needed. Following these practical clearance and access guidelines will maintain reliable operation within the specified 2–10 bar pressure range.

Aluminum Pneumatic Valve VOR with Enhanced Signal Control

All products, Pneumatic valves/

Additional information

Material	AL – aluminum

The VOR series higher signal valve is a reliable solution for applications requiring precise signal separation, ensuring that the stronger of two input signals is always selected without any mutual interference. Designed to operate within a pressure range of 2 to 10 bar and a temperature span from -10°C to +80°C, it guarantees consistent performance even in demanding industrial environments. Its robust aluminum body provides durability and resistance to wear, while the NBR sealing ensures tightness and long-lasting efficiency. Thanks to its compact design and high-quality materials, the valve is easy to integrate into various pneumatic systems, delivering dependable functionality and reducing downtime. Ideal for industries seeking efficiency, reliability, and precision, the VOR series valve enhances system performance while maintaining low maintenance requirements.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]	Enquiry	Catalogue
MW-W3603000001	VOR higher signal valve, 3 x GW BSP 1/8"	-	10
MW-W3603000002	VOR higher signal valve, 3 x GW BSP 1/4"	-	10

The VOR series higher signal valve is a reliable solution for applications requiring precise signal separation, ensuring that the stronger of two input signals is always selected without any mutual interference. Designed to operate within a pressure range of 2 to 10 bar and a temperature span from -10°C to +80°C, it guarantees consistent performance even in demanding industrial environments. Its robust aluminum body provides durability and resistance to wear, while the NBR sealing ensures tightness and long-lasting efficiency. Thanks to its compact design and high-quality materials, the valve is easy to integrate into various pneumatic systems, delivering dependable functionality and reducing downtime. Ideal for industries seeking efficiency, reliability, and precision, the VOR series valve enhances system performance while maintaining low maintenance requirements.
