Valve check stainless with a female BSP thread, type 2050

Additional information

Material

SS – stainless steel

A universal valve check type 2050 intended for securing installation against a stream return the medium working. It can be used for air, gases, water, chemicals, products petrochemical, etc., taking into account resistance chemical material valve. valve must be mounted in accordance with direction flow the medium indicated on body. pressure working dependent is od temperatures use. Material body: cast steel stainless CF8M. Material spring: steel AISI 304. butterfly valve: steel AISI 316. sealing: PTFE. Connection: BSP female. Operating temperature: od -20°C up to +200°C. Working pressure: up to 13 bar (+200°C), up to 50 bar (+40°C).

List of product variants

Article numberProduct variant nameDNBARAvailabilityPriceQuantityActionsCatalogue
HT-2050-08Check valve with 1/4" BSP female, AISI 316850In stock0 €
Enquiry
HT-2050-10Check valve with 3/8" BSP female, AISI 3161050In stock0 €
Enquiry
HT-2050-15Check valve with 1/2" BSP female, AISI 3161650In stock0 €
Enquiry
HT-2050-20Check valve with 3/4" BSP female, AISI 3162050In stock0 €
Enquiry
HT-2050-25Check valve with 1" BSP female, AISI 3162550In stock0 €
Enquiry
HT-2050-32Check valve with 1.1/4" BSP female, AISI 3163250In stock0 €
Enquiry
HT-2050-40Check valve with 1.1/2" BSP female, AISI 3164050In stock0 €
Enquiry
HT-2050-50Check valve with 2" BSP female, AISI 3165050In stock0 €
Enquiry

Do you need a larger quantity of products or a bespoke quote?

A universal valve check type 2050 intended for securing installation against a stream return the medium working. It can be used for air, gases, water, chemicals, products petrochemical, etc., taking into account resistance chemical material valve. valve must be mounted in accordance with direction flow the medium indicated on body. pressure working dependent is od temperatures use. Material body: cast steel stainless CF8M. Material spring: steel AISI 304. butterfly valve: steel AISI 316. sealing: PTFE. Connection: BSP female. Operating temperature: od -20°C up to +200°C. Working pressure: up to 13 bar (+200°C), up to 50 bar (+40°C).

Additional information

Material

SS – stainless steel
