Can the DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type be used with high-pressure hydraulic systems and which crimping sleeve is recommended?

Yes. The DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type can be used in high‑pressure hydraulic systems. Its DKR 60° sealing cone, internal BSP thread with nut, robust carbon steel construction and zinc finish are specifically described to provide tight, leak‑free performance and good wear/corrosion resistance under demanding, high‑pressure conditions. For hose assembly, use a crimping sleeve matched to the specific hose type and size being used; the fitting is engineered to be crimped with a sleeve that corresponds to the hose manufacturer’s recommendations to ensure a secure, industry‑standard connection.

Is the DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type compatible with different hose materials (e.g., PTFE, rubber, thermoplastic) and their specific crimp sleeve requirements?

Yes — the DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type is compatible with different hose materials, provided the correct crimp sleeve and assembly procedure for each hose type are used. Key points: - The fitting features a standard hydraulic tail and is engineered to accept crimping sleeves matched to the hose type. That design intent means it can be used with PTFE, rubber, thermoplastic and other common hydraulic hose constructions. - Compatibility depends on selecting the correct sleeve profile, material and crimp dimensions for the specific hose (manufacturer-recommended ferrule/sleeve for PTFE liners, for rubber braided hoses, or for thermoplastic hoses). Using the wrong sleeve or crimp parameters can compromise seal integrity and mechanical retention. - The DKR 60° sealing cone and internal BSP thread with nut provide a reliable metal-to-metal seal and mechanical clamping; however PTFE hoses often require an insert or specific ferrule to prevent liner collapse and ensure sealing, while thermoplastic hoses may require sleeves that account for their different compressibility. - Because the fitting is made of carbon steel with zinc plating, ensure sleeve material and crimping process are compatible to avoid galvanic or mechanical issues in your environment. Recommendation: consult the hose and sleeve manufacturers’ specifications and crimping charts and follow industry-standard assembly procedures to select the exact sleeve type and crimping parameters for PTFE, rubber, or thermoplastic hoses when using the DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type.

DKR 90° Hydraulic Fitting ZBW210, Carbon Steel, Y-Type

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)

The 90° angled hydraulic end, type Z, is a reliable solution designed for secure and efficient hose connections in demanding hydraulic and industrial applications. Equipped with a standard hydraulic tail for hose assembly, an internal BSP thread with nut, and a precise 60° sealing cone (DKR), it ensures tight, leak-free performance even under high pressure. Manufactured from durable carbon steel and finished with a protective zinc coating, the fitting offers excellent resistance to wear and corrosion, extending service life and reducing maintenance needs. Engineered for use with crimping sleeves matched to the hose type, it guarantees a strong, professional connection that meets industry standards. Its robust construction and precise geometry make it an ideal choice for applications requiring reliability, safety, and long-term durability, while the angled design provides flexibility in installations where space is limited or routing requires a compact solution.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZBW210-06-05-Y	End. 90° G 3/8" BSP, hose 5/16", cone 60°	8	-	In stock	Enquiry
TI-ZBW210-06-06-Y	End fitting 90° G 3/8" BSP, hose 3/8", cone 60°	10	-	In stock	Enquiry
TI-ZBW210-08-05-Y	End fitting 90° G 1/2" BSP, hose 5/16", cone 60°	8	-	In stock	Enquiry
TI-ZBW210-08-06-Y	End. 90° G 1/2" BSP, hose 3/8", cone 60°	10	-	In stock	Enquiry
TI-ZBW210-08-08-Y	End fitting 90° GW 1/2" BSP, hose 1/2", cone 60°	12	-	In stock	Enquiry
TI-ZBW210-12-08-Y	End fitting 90° G 3/4" BSP, hose 1/2", cone 60°	12	-	In stock	Enquiry
TI-ZBW210-12-10-Y	End. 90° G 3/4" BSP, hose 5/8", cone 60°	16	-	In stock	Enquiry
TI-ZBW210-12-12-Y	End fitting 90° G 3/4" BSP, hose 3/4", cone 60°	20	-	In stock	Enquiry
TI-ZBW210-20-16-Y	End fitting 90° G 1.1/4" BSP hose 1", cone 60°	25	-	In stock	Enquiry
TI-ZBW210-20-20-Y	Elbow 90° G 1.1/4" BSP, hose 1.1/4", cone 60°	32	-	In stock	Enquiry
TI-ZBW210-24-20-Y	Elbow 90° G 1.1/2" BSP, hose 1.1/4", cone 60°	32	-	In stock	Enquiry
TI-ZBW210-24-24-Y	Elbow 90° G1.1/2" BSP, hose 1.1/2", cone 60°	38	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +91 8 925 918 796 or email us: chennai@tubes-international.com

SEND ENQUIRY

The 90° angled hydraulic end, type Z, is a reliable solution designed for secure and efficient hose connections in demanding hydraulic and industrial applications. Equipped with a standard hydraulic tail for hose assembly, an internal BSP thread with nut, and a precise 60° sealing cone (DKR), it ensures tight, leak-free performance even under high pressure. Manufactured from durable carbon steel and finished with a protective zinc coating, the fitting offers excellent resistance to wear and corrosion, extending service life and reducing maintenance needs. Engineered for use with crimping sleeves matched to the hose type, it guarantees a strong, professional connection that meets industry standards. Its robust construction and precise geometry make it an ideal choice for applications requiring reliability, safety, and long-term durability, while the angled design provides flexibility in installations where space is limited or routing requires a compact solution.
