Food-Grade Braided Hose TYGON® S3™ B-44-4X I.B. for Dairy and Food Use

This high-performance, flexible hose made of special PVC with reinforced polyester braid is engineered for safe and efficient transfer of food products under elevated pressure. Its smooth, non-porous inner surface prevents residue buildup and bacterial growth, ensuring maximum hygiene and product purity. Completely odorless, tasteless, non-toxic, and free from phthalates and BPA, it fully complies with the most rigorous international food contact standards, including EU 1935/2004/EC and 10/2011, FDA, NSF-51, NSF-61, 3-A, Japanese #370/1959, MHLW370(3-D), as well as REACH and California Proposition 65. Resistant to alkaline cleaning agents, the hose can be sterilized with ethylene oxide and, when equipped with hygienic fittings, supports CIP cleaning processes. With a maximum operating temperature of +74°C, brittleness resistance down to -36°C, hardness of 66° Shore (A), and density of 1.21 g/cm³, it guarantees durability and reliability in demanding applications. Available in 15 m rolls (from 38.1 mm internal diameter – 6 m), it offers a working pressure defined by a 1:4 safety factor relative to burst pressure. Packaged in the CLEAN ROOM of Tubes International to meet strict hygiene standards, this product ensures uncompromising quality and safety, making it the ideal choice for modern food and beverage processing environments.

List of product variants

Article numberProduct variant nameNominal inner diameterWorking pressure [bar]Enquiry
VE-T1408-33Hose TYGON S3 B-44-4X I.B. 6.4x11.2 mm617.2
VE-T1412-43Hose TYGON S3 B-44-4X I.B. 9.5x15.9 mm1011.7
VE-T1432-63Hose TYGON S3 B-44-4X I.B. 25.4x35 mm256.9

This high-performance, flexible hose made of special PVC with reinforced polyester braid is engineered for safe and efficient transfer of food products under elevated pressure. Its smooth, non-porous inner surface prevents residue buildup and bacterial growth, ensuring maximum hygiene and product purity. Completely odorless, tasteless, non-toxic, and free from phthalates and BPA, it fully complies with the most rigorous international food contact standards, including EU 1935/2004/EC and 10/2011, FDA, NSF-51, NSF-61, 3-A, Japanese #370/1959, MHLW370(3-D), as well as REACH and California Proposition 65. Resistant to alkaline cleaning agents, the hose can be sterilized with ethylene oxide and, when equipped with hygienic fittings, supports CIP cleaning processes. With a maximum operating temperature of +74°C, brittleness resistance down to -36°C, hardness of 66° Shore (A), and density of 1.21 g/cm³, it guarantees durability and reliability in demanding applications. Available in 15 m rolls (from 38.1 mm internal diameter – 6 m), it offers a working pressure defined by a 1:4 safety factor relative to burst pressure. Packaged in the CLEAN ROOM of Tubes International to meet strict hygiene standards, this product ensures uncompromising quality and safety, making it the ideal choice for modern food and beverage processing environments.

Additional information

Material

PVC – polyvinyl chloride

Maximum operating temperature [°C]

74

Vacuum resistance

yes

Standard length [m]

15, 6

Additional information

Material

PVC – polyvinyl chloride

Maximum operating temperature [°C]

74

Vacuum resistance

yes

Standard length [m]

15, 6
