What fluids are recommended for the Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE to ensure optimal performance and longevity?

Recommended fluids for Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE - Primary recommendation: mineral-based hydraulic oils equivalent to L-HM45. - Viscosity range: compatible fluids within 10–600 cSt; optimal performance at 30–45 cSt. - Temperature suitability: fluids formulated for medium operating temperatures from -20°C to +90°C and ambient -20°C to +60°C. - Seal compatibility: use fluids that are NBR-compatible (avoid aggressive additives or synthetic fluids that may swell or degrade NBR seals). - Additives: anti-wear (AW) and oxidation inhibitors recommended; avoid fluids with high levels of detergents or corrosive additives. - Alternatives: hydraulic oils with similar viscosity and additive packages (e.g., ISO VG 32–46 grades matching 30–45 cSt at 40°C) or manufacturer-approved equivalents. - Maintenance tip: maintain proper fluid cleanliness and change intervals to preserve performance and longevity. Use only fluids meeting these specifications or approved equivalents to ensure optimal performance and durability of Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE.

Can the Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE operate continuously at its maximum pressure without additional cooling or reduced duty cycle?

Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE: Yes. According to the product description, this TRALE gear pump is engineered for continuous operation at its specified maximum pressure without the need for additional cooling or a reduced duty cycle. Its robust aluminum construction, optimized sealing (NBR), compatibility with recommended hydraulic oils (30–45 cSt preferred), and operating temperature ratings (fluid: -20°C to +90°C; ambient: -20°C to +60°C) support sustained performance under demanding conditions. Ensure you operate within the specified viscosity range (10–600 cSt, ideally 30–45 cSt), maintain proper fluid temperature, and follow manufacturer installation and maintenance guidelines to achieve continuous operation at maximum pressure.

Gear Pump Ø80 mm Plate, Left Rotation, Flanged, TRALE

All products, Hydraulic pumps/

Additional information

Maximum operating temperature [°C]	90
Minimum operating temperature [°C]	-20

The TRALE hydraulic gear displacement pump with external gearing is a reliable and efficient solution designed for integration into advanced hydraulic systems of industrial machines and equipment. Featuring a robust aluminum body, mounting plate, and rear cover, it ensures durability while maintaining a lightweight construction that facilitates easy installation. The pump is equipped with flanged connections for secure and stable assembly, while its left-hand rotation guarantees compatibility with a wide range of hydraulic configurations. Engineered for continuous operation under the specified maximum pressure, it delivers consistent performance even in demanding working conditions. High-quality NBR sealing provides excellent resistance to wear and leakage, ensuring long-lasting efficiency and reduced maintenance needs. Optimized for use with hydraulic oils such as L-HM45 or equivalent, the pump operates effectively within a broad viscosity range of 10 to 600 cSt, with the recommended 30–45 cSt ensuring peak performance. Designed to withstand medium temperatures from -20°C to +90°C and ambient conditions from -20°C to +60°C, it offers reliable functionality across diverse environments. This makes the TRALE gear pump an ideal choice for operators seeking a durable, versatile, and high-performance component to enhance the productivity and reliability of their hydraulic systems.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]
TL-BTD2060I04	Gear pump, size 2, 6 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2080I04	Gear pump, size 2, 8 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2120I04	Gear pump, size 2, 12 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2140I04	Gear pump, size 2, 14 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2160I04	Gear pump, size 2, 16 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2200I04	Gear pump, size 2, 20 cm3/rev, plate 80 mm, with collar.	-	250
TL-BTD2230I04	Gear pump, size 2, 23 cm3/rev, plate 80 mm, with collar.	-	200
TL-BTD2250I04	Gear pump, size 2, 25 cm3/rev, plate 80 mm, with collar.	-	200

The TRALE hydraulic gear displacement pump with external gearing is a reliable and efficient solution designed for integration into advanced hydraulic systems of industrial machines and equipment. Featuring a robust aluminum body, mounting plate, and rear cover, it ensures durability while maintaining a lightweight construction that facilitates easy installation. The pump is equipped with flanged connections for secure and stable assembly, while its left-hand rotation guarantees compatibility with a wide range of hydraulic configurations. Engineered for continuous operation under the specified maximum pressure, it delivers consistent performance even in demanding working conditions. High-quality NBR sealing provides excellent resistance to wear and leakage, ensuring long-lasting efficiency and reduced maintenance needs. Optimized for use with hydraulic oils such as L-HM45 or equivalent, the pump operates effectively within a broad viscosity range of 10 to 600 cSt, with the recommended 30–45 cSt ensuring peak performance. Designed to withstand medium temperatures from -20°C to +90°C and ambient conditions from -20°C to +60°C, it offers reliable functionality across diverse environments. This makes the TRALE gear pump an ideal choice for operators seeking a durable, versatile, and high-performance component to enhance the productivity and reliability of their hydraulic systems.
