Is the CAMLOCK DC Dust Cap, Polypropylene Plug Cover compatible with potable water and food-grade applications?

CAMLOCK DC Dust Cap, Polypropylene Plug Cover is suitable for potable water and many food‑grade applications with some important caveats. The cap’s body is made of fiberglass‑reinforced polypropylene and the sealing element is EPDM, both materials commonly accepted for contact with water and many foodstuffs due to good chemical resistance and flexibility. The AISI 304 stainless‑steel lever adds corrosion resistance useful in wet environments. However, suitability for potable water and food‑grade use depends on specific regulatory and certification requirements in your region (e.g., NSF/ANSI, FDA, WRAS). The provided description does not state explicit potable‑water or food‑contact certifications. Before use in certified potable or food applications, confirm with the manufacturer that the exact part has the necessary approvals and that EPDM and fiberglass‑reinforced polypropylene grades used meet local food‑contact and potable‑water standards. If certifications are present, the CAMLOCK DC Dust Cap, Polypropylene Plug Cover can be used safely for potable water and compatible food‑grade fluids.

Can the CAMLOCK DC Dust Cap, Polypropylene Plug Cover withstand exposure to aggressive chemicals or solvents commonly used in industrial cleaning?

Yes — the CAMLOCK DC Dust Cap, Polypropylene Plug Cover is formulated to resist many aggressive chemicals and solvents commonly used in industrial cleaning, but with important limits. Why it resists chemicals: - Polypropylene reinforced with fiberglass provides strong chemical resistance and mechanical durability. - EPDM sealing offers excellent compatibility with water and many cleaning agents, plus good flexibility and wear resistance. - AISI 304 stainless steel lever adds corrosion resistance in typical industrial environments. Limitations and cautions: - EPDM is not compatible with strong ketones (e.g., acetone), many chlorinated solvents, aromatic hydrocarbons, and some aggressive acids/alkalis — these can degrade the seal or polymer over time. - AISI 304 resists many corrosives but can be attacked by strong chlorides, certain acids, or high-temperature corrosive atmospheres. - Actual resistance depends on chemical concentration, temperature, exposure duration and frequency. Recommendation: For critical or prolonged exposure, verify compatibility against the specific chemical (concentration and temperature) using manufacturer chemical-resistance data or perform a compatibility test. If exposure includes known EPDM/polypropylene/304-incompatible solvents, consider alternative materials or protective measures.

CAMLOCK DC Dust Cap, Polypropylene Plug Cover

Additional information

Material	P – material (plastic)

The plug cap for CAMLOCK DC coupling is manufactured in compliance with the American military standard MIL-C-27487 (A-A-59326), ensuring reliability and durability even in demanding industrial environments. Designed to withstand working pressures of up to 7 bar, depending on the coupling size, it provides secure and leak-free performance across a wide range of applications. The body is made of high-quality polypropylene reinforced with fiberglass, delivering excellent resistance to mechanical stress, chemicals, and temperature variations. For enhanced safety and ease of use, the lever is crafted from robust AISI 304 stainless steel, guaranteeing long-lasting functionality and corrosion resistance. The sealing element is made of EPDM, offering outstanding flexibility, tightness, and resistance to wear, making it ideal for use with water, certain chemicals, and other compatible media. This combination of advanced materials and precise engineering ensures a dependable solution for industries seeking efficiency, safety, and durability in fluid handling systems.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]
AC-DC-075-P	CAMLOCK connector DC 3/4" polypropylene	-	7
AC-DC-075-PX	CAMLOCK connector DC 3/4" polypropylene	-	7
AC-DC-100-P	CAMLOCK DC 1" polypropylene connector	-	7
AC-DC-100-PX	CAMLOCK DC 1" polypropylene connector	-	7
AC-DC-125-P	CAMLOCK DC 1.1/4" connector, polypropylene	-	7
AC-DC-125-PX	CAMLOCK DC 1.1/4" connector, polypropylene	-	7
AC-DC-150-P	CAMLOCK connector DC 1.1/2" polypropylene	-	7
AC-DC-150-PX	CAMLOCK DC 1.1/2 polypropylene connector	-	7
AC-DC-200-P	CAMLOCK DC 2" polypropylene connector	-	7
AC-DC-200-PX	CAMLOCK DC 2" polypropylene connector	-	7
AC-DC-300-P	CAMLOCK DC 3" polypropylene connector	-	4
AC-DC-300-PX	CAMLOCK DC 3" polypropylene connector	-	4
AC-DC-400-P	CAMLOCK connector DC 4" polypropylene	-	4
AC-DC-400-PX	CAMLOCK connector DC 4", polypropylene	-	4

The plug cap for CAMLOCK DC coupling is manufactured in compliance with the American military standard MIL-C-27487 (A-A-59326), ensuring reliability and durability even in demanding industrial environments. Designed to withstand working pressures of up to 7 bar, depending on the coupling size, it provides secure and leak-free performance across a wide range of applications. The body is made of high-quality polypropylene reinforced with fiberglass, delivering excellent resistance to mechanical stress, chemicals, and temperature variations. For enhanced safety and ease of use, the lever is crafted from robust AISI 304 stainless steel, guaranteeing long-lasting functionality and corrosion resistance. The sealing element is made of EPDM, offering outstanding flexibility, tightness, and resistance to wear, making it ideal for use with water, certain chemicals, and other compatible media. This combination of advanced materials and precise engineering ensures a dependable solution for industries seeking efficiency, safety, and durability in fluid handling systems.
