What is the maximum noise reduction achievable with the Brass Muffler MWSCQ with GZ at 5 bar, 1 m distance, 45°?

The maximum noise reduction achievable with the Brass Muffler MWSCQ with GZ at 5 bar, 1 m distance, 45° is up to 35 dB.

How should the Brass Muffler MWSCQ with GZ be installed to ensure optimal noise reduction and system performance?

To ensure optimal noise reduction and reliable system performance, install the Brass Muffler MWSCQ with GZ as follows: - Choose correct location: mount the Brass Muffler MWSCQ with GZ directly on the exhaust port of the pneumatic component, ensuring unobstructed flow and that the silencer axis points into open space (avoid directing toward walls or confined areas). - Threading and sealing: screw the external thread fully and securely into the mating port using appropriate thread sealant or PTFE tape if required by the system, taking care not to over-tighten and damage threads or silencer housing. - Orientation and clearance: maintain at least 1 m clear distance in the primary noise-measurement direction and keep surrounding area free from blocking objects to preserve acoustic performance and cooling. - Pressure and temperature limits: confirm system operates within -10°C to +80°C and up to 12 bar; do not exceed these limits to prevent performance loss or damage. - Maintenance access: install so the Brass Muffler MWSCQ with GZ is accessible for periodic inspection and replacement; clean or replace if flow restriction or contamination occurs. - Compatibility: ensure materials (nickel-plated brass and sintered bronze) are suitable for the process media to avoid corrosion or premature wear. - Safety check: after installation pressurize system slowly, inspect for leaks and proper seating, and verify noise reduction meets expectations (typical up to 35 dB at 5 bar, 1 m, 45°). Following these steps will maximize acoustic attenuation and ensure durable, trouble-free operation.

Silencer MWSCQ with male thread, brass

All products, Equipment for pneumatic valves/

Additional information

Material	B – brass (bronze)

Silencer MWSCQ with thread external used in systems compressed air in order to reducing level noise. reducer noise that can obtain through assembly silencer, measured at pressure supply 5 bar, in distance 1m and under angle 45° od axis silencer, is average depending on size 35 dB. Material: brass nickel-plated, bronze sintered nickel-plated. Operating temperature: od -10°C up to +80°C. Working pressure: up to 12 bar.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
MW-W0970530012	Silencer MW SCQ, brass/bronze nickel-plated, 1/8" BSP male	-	-	In stock	Enquiry
MW-W0970530013	Silencer MW SCQ, brass/bronze nickel-plated, 1/4" BSP male	-	-	In stock	Enquiry
MW-W0970530014	Silencer MW SCQ, brass/bronze nickel-plated, 3/8" BSP male	-	-	In stock	Enquiry
MW-W0970530015	Silencer MW SCQ, brass/bronze nickel-plated, 1/2" BSP male	-	-	In stock	Enquiry
MW-W0970530016	Silencer MW SCQ, brass/bronze nickel-plated, 3/4" BSP male	-	-	In stock	Enquiry
MW-W0970530017	Silencer MW SCQ, brass/bronze nickel-plated, 1" BSP male	-	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +91 8 925 918 796 or email us: chennai@tubes-international.com

SEND ENQUIRY

Silencer MWSCQ with thread external used in systems compressed air in order to reducing level noise. reducer noise that can obtain through assembly silencer, measured at pressure supply 5 bar, in distance 1m and under angle 45° od axis silencer, is average depending on size 35 dB. Material: brass nickel-plated, bronze sintered nickel-plated. Operating temperature: od -10°C up to +80°C. Working pressure: up to 12 bar.
