Hose for pumps peristaltic for applications pharmaceutical and biotechnological PHARMED® BPT

Additional information

Material

TPE – thermoplastic elastomer

Maximum operating temperature [°C]

135

Minimum operating temperature [°C]

-51

Vacuum resistance

yes

Standard length [m]

7.5

High quality, flexible hose in color cream, designed specially for industry pharmaceutical, biotechnology and laboratories. has high resistance fatigue, exceptionally high service life in use in pump peristaltic and good resistance to flaking („spallation” – crumbling microparticles material hose in result pressure rotor pump). is characterized also very low permeability for media gas, low level absorption conveyed products, good resistance on acids, bases and oxidation. ideal for use in processes diagnostics, sampling and culture cultures cellular in vitro, generating vaccines, for bioreactors, sterile lines filling, processes fermentation, extraction and purification (purification). opaque wall hose protects sensitive products against radiation UV. hose is compliant with requirements USP CLASS VI and is completely not cytotoxic, not hemolytic and not pyrogenic. compliant with ISO 10993 for contact with blood, fluids body and tissues for 30 dni. Meets the requirements of NSF-51 for contact with food. possible multiple sterilization steam in autoclaves (30 min, 1 bar, 121°C), cleaning CIP and SIP installation, oxide ethylene or radiation (gamma Cobalt 60 for 5 Mrad). resistant to flame (UL 94-HB). length full roll hose 7.5 m. pressure working determined relative to pressure bursting at factor safety 1:5. Material: thermoplastic elastomer (TPE). Operating temperature: od -51°C up to +135°C. temperature brittleness: -75°C. Hardness: 64° Shore (A). Density: 0.98 g/cm³. Note: The product is packaged in the Tubes International Clean Zone (CLEAN ROOM) in compliance with rigorous standards. Return of the product after opening the package is not possible.

List of product variants

Article numberProduct variant nameDNBARAvailabilityPriceQuantityActionsCatalogue
VE-R6501-26BPTHose PHARMED BPT 0.8x4 mm15.38In stock0 €
Enquiry
VE-R6502-16BPTHose PHARMED BPT 1.6x3.2 mm21.65In stock0 €
Enquiry
VE-R6502-26BPTHose PHARMED BPT 1.6x4.8 mm22.96In stock0 €
Enquiry
VE-R6503-26BPTHose PHARMED BPT 2.4x5.6 mm22.07In stock0 €
Enquiry
VE-R6504-16BPTHose PHARMED BPT 3.2x4.8 mm20.9In stock0 €
Enquiry
VE-R6504-26BPTHose PHARMED BPT 3.2x6.4 mm31.65In stock0 €
Enquiry
VE-R6506-26BPTHose PHARMED BPT 4.8x8 mm51.17In stock0 €
Enquiry
VE-R6508-26BPTHose PHARMED BPT 6.4x9.5 mm50.9In stock0 €
Enquiry
VE-R6508-36BPTHose PHARMED BPT 6.35x11.15 mm61.28In stock0 €
Enquiry
VE-R6508-46BPTHose PHARMED BPT 6.4x12.7 mm61.65In stock0 €
Enquiry
VE-R650E-26BPTHose PHARMED BPT 0.5x3.7 mm17.93In stock0 €
Enquiry
VE-R6510-26BPTHose PHARMED BPT 8x11.1 mm80.76In stock0 €
Enquiry
VE-R6512-26BPTHose PHARMED BPT 9.5x12.7 mm100.62In stock0 €
Enquiry
VE-R6512-36BPTHose PHARMED BPT 9.5x14.3 mm100.9In stock0 €
Enquiry
VE-R6512-46BPTHose PHARMED BPT 9.5x15.9 mm101.17In stock0 €
Enquiry
VE-R6516-46BPTHose PHARMED BPT 12.7x19.1 mm120.69In stock0 €
Enquiry
VE-R6520-46BPTHose PHARMED BPT 15.9x22.2 mm160.76In stock0 €
Enquiry
VE-R6524-46BPTHose PHARMED BPT 19x25.4 mm200.62In stock0 €
Enquiry

Do you need a larger quantity of products or a bespoke quote?

High quality, flexible hose in color cream, designed specially for industry pharmaceutical, biotechnology and laboratories. has high resistance fatigue, exceptionally high service life in use in pump peristaltic and good resistance to flaking („spallation” – crumbling microparticles material hose in result pressure rotor pump). is characterized also very low permeability for media gas, low level absorption conveyed products, good resistance on acids, bases and oxidation. ideal for use in processes diagnostics, sampling and culture cultures cellular in vitro, generating vaccines, for bioreactors, sterile lines filling, processes fermentation, extraction and purification (purification). opaque wall hose protects sensitive products against radiation UV. hose is compliant with requirements USP CLASS VI and is completely not cytotoxic, not hemolytic and not pyrogenic. compliant with ISO 10993 for contact with blood, fluids body and tissues for 30 dni. Meets the requirements of NSF-51 for contact with food. possible multiple sterilization steam in autoclaves (30 min, 1 bar, 121°C), cleaning CIP and SIP installation, oxide ethylene or radiation (gamma Cobalt 60 for 5 Mrad). resistant to flame (UL 94-HB). length full roll hose 7.5 m. pressure working determined relative to pressure bursting at factor safety 1:5. Material: thermoplastic elastomer (TPE). Operating temperature: od -51°C up to +135°C. temperature brittleness: -75°C. Hardness: 64° Shore (A). Density: 0.98 g/cm³. Note: The product is packaged in the Tubes International Clean Zone (CLEAN ROOM) in compliance with rigorous standards. Return of the product after opening the package is not possible.

Additional information

Material

TPE – thermoplastic elastomer

Maximum operating temperature [°C]

135

Minimum operating temperature [°C]

-51

Vacuum resistance

yes

Standard length [m]

7.5

Do you need a larger quantity of products or a bespoke quote?
