Hose fuel for small engines o very low permeability vapours TYGON® LP-1200

Additional information

Material

PVDF – polyvinylidene fluoride

Maximum operating temperature [°C]

82

Minimum operating temperature [°C]

-28

Vacuum resistance

yes

Standard length [m]

15, 30

Colorless, transparent, flexible hose fuel o exceptionally low permeability vapours fuels through wall hose. meets American requirements EPA and CARB (permeability for 15 g/m2/24h). patented multilayer The design hose o internal layer with fluoropolymer PVDF resistant to fuels with content ethanol up to 100%. resistant to swelling and hardening on result operation hydrocarbons, reduces significantly risk cracking and leakage. minimum extractability secures cleanliness fuels, a exceptionally low factor penetration substances aromatic secures the operator and environment. resistant to ozone and radiation UV (ANSI B175.1 D). flexibility hose facilitates its installations even in tight places and is maintained also in low temperatures, co ensures trouble-free sampling fuels in each position. transparent wall allows on monitoring flow. thanks to internal layer with PVDF hose is resistant to most substances chemical and fuels. can be submerged in fuel (not recommended only repeated use in high temperatures external). flame-retardant (UL 94 HB). used in modern mowers, saws chain, drills combustion, trimmers for hedges, etc. machines garden. length full roll hose 15 m. pressure working determined relative to pressure bursting at factor safety 1:5. Material: PVDF / TPE (multilayer). Operating temperature: od -40°C up to +82°C. temperature brittleness: -90°C. Hardness: 78° Shore (A). Density: 1.27 g/cm³. Note: The product is packaged in the Tubes International Clean Zone (CLEAN ROOM) in compliance with rigorous standards. Return of the product after opening the package is not possible.

List of product variants

Article numberProduct variant nameDNBARAvailabilityPriceQuantityActionsCatalogue
VE-ALR00007Hose TYGON LP-1200 3.2x6.4 mm34.14In stock0 €
Enquiry
VE-ALR00012Hose TYGON LP-1200 4.8x8 mm53.1In stock0 €
Enquiry
VE-ALR00017Hose TYGON LP-1200 6.4x9.6 mm62.07In stock0 €
Enquiry
VE-ALR00165Hose TYGON LP-1200 2.4x4.8 mm24.48In stock0 €
Enquiry
VE-ALR00700Hose TYGON LP-1200 2.03x3.56 mm24.83In stock0 €
Enquiry

Do you need a larger quantity of products or a bespoke quote?

Colorless, transparent, flexible hose fuel o exceptionally low permeability vapours fuels through wall hose. meets American requirements EPA and CARB (permeability for 15 g/m2/24h). patented multilayer The design hose o internal layer with fluoropolymer PVDF resistant to fuels with content ethanol up to 100%. resistant to swelling and hardening on result operation hydrocarbons, reduces significantly risk cracking and leakage. minimum extractability secures cleanliness fuels, a exceptionally low factor penetration substances aromatic secures the operator and environment. resistant to ozone and radiation UV (ANSI B175.1 D). flexibility hose facilitates its installations even in tight places and is maintained also in low temperatures, co ensures trouble-free sampling fuels in each position. transparent wall allows on monitoring flow. thanks to internal layer with PVDF hose is resistant to most substances chemical and fuels. can be submerged in fuel (not recommended only repeated use in high temperatures external). flame-retardant (UL 94 HB). used in modern mowers, saws chain, drills combustion, trimmers for hedges, etc. machines garden. length full roll hose 15 m. pressure working determined relative to pressure bursting at factor safety 1:5. Material: PVDF / TPE (multilayer). Operating temperature: od -40°C up to +82°C. temperature brittleness: -90°C. Hardness: 78° Shore (A). Density: 1.27 g/cm³. Note: The product is packaged in the Tubes International Clean Zone (CLEAN ROOM) in compliance with rigorous standards. Return of the product after opening the package is not possible.

Additional information

Material

PVDF – polyvinylidene fluoride

Maximum operating temperature [°C]

82

Minimum operating temperature [°C]

-28

Vacuum resistance

yes

Standard length [m]

15, 30

Do you need a larger quantity of products or a bespoke quote?
