Aluminum Splitter Bar with Opposite 1/8″ to 1/4″ Outputs
The dividing rail with opposing 1/8″ and 1/4″ outputs is a practical solution for efficient distribution of compressed air in pneumatic systems, enabling smooth redirection of pressure to multiple branches. Designed with additional mounting holes, it can be securely fixed in the optimal position within any installation, ensuring stability and reliability. Manufactured from durable anodized aluminum, it guarantees long-lasting resistance to wear and corrosion, even in demanding industrial environments. With a working pressure of up to 12 bar and an operating temperature range from -10°C to +80°C, this component offers versatility and dependable performance across a wide spectrum of applications. Its compact yet robust construction makes it an excellent choice for professionals seeking efficiency, safety, and precision in compressed air management.
List of product variants
| Article number | Product variant name | Nominal inner diameter | Working pressure [bar] | Enquiry |
|---|---|---|---|---|
| MW-W0503111015 | Double-sided distribution strip, 2 x inlet G 1/4", 6 x outlet G 1/8", aluminum | - | 12 | |
| MW-W0503111017 | Dual-sided distribution bar, 2 x inlet G thread BSP 1/4", 8 x outlet G thread BSP 1/8", aluminum | - | 12 | |
| MW-W0503111019 | Dual-sided distribution bar, 2 x inlet G 1/4", 10 x outlet G 1/8", aluminum | - | 12 | |
| MW-W0503121016 | Double-sided distribution bar, 2 x inlet G 3/8", 6 x outlet G 1/4", aluminum | - | 12 | |
| MW-W0503121018 | Dual-sided distribution bar, 2 x inlet G 3/8", 8 x outlet G 1/4", aluminum | - | 12 | |
| MW-W0503121020 | Double-sided distribution bar, 2 x inlet G 3/8", 10 x outlet G 1/4", aluminum | - | 12 | |
| MW-W0503131016 | Dual-sided distribution bar, 2 x inlet G 1/2", 6 x outlet G 1/4", aluminum | - | 12 | |
| MW-W0503131018 | Dual-sided distribution bar, 2 x inlet G 1/2", 8 x outlet G 1/4", aluminum | - | 12 | |
| MW-W0503131020 | Dual-sided distribution bar, 2 x inlet G 1/2", 10 x outlet G 1/4", aluminum | - | 12 |
The dividing rail with opposing 1/8″ and 1/4″ outputs is a practical solution for efficient distribution of compressed air in pneumatic systems, enabling smooth redirection of pressure to multiple branches. Designed with additional mounting holes, it can be securely fixed in the optimal position within any installation, ensuring stability and reliability. Manufactured from durable anodized aluminum, it guarantees long-lasting resistance to wear and corrosion, even in demanding industrial environments. With a working pressure of up to 12 bar and an operating temperature range from -10°C to +80°C, this component offers versatility and dependable performance across a wide spectrum of applications. Its compact yet robust construction makes it an excellent choice for professionals seeking efficiency, safety, and precision in compressed air management.
Additional information
| Material | AL – aluminum |
|---|
